MC-24

Modular Contactor 24V ac/dc Coil (Hum Free)

Inner Carton
units
Outer Carton
units

7 years warranty

MC-25-24-1NO1NC MC-25-24-2NO
Coil Voltage 24Vac/dc 24Vac/dc
Maximum Load Current
AC-1 AC-7a AC-21 AC-22 25A 25A
AC-3 AC-23 AC-7b NO 9A, NC 6A 9A
AC-2 AC-5a 11A 11A
LED Lighting 3.8A 3.8A
Number of Poles 2 2
N/O Contacts 1 2
N/C Contacts 1 -
Manual Override No No
Width (DIN Module) 1 1
Power Dissipation Per Pole 2W 2W
Contact Terminal Capacity 10mm2 10mm2
Coil Terminal Capacity 2.5mm2 2.5mm2
Coil Power Consumption 2W 2W
Suitable for Auxilliary Contact No No
Hum Free Yes Yes
Operation Ambient Temperature -15oC to +55oC -15oC to +55oC
Storage Temperature -40oC to +80oC -40oC to +80oC
Maximum Mounted side-by-side 2 2
Weight 130g 130g

Attachment
MC-24 Product Datasheet
Modular Contactors Range Technical Specifications
