- The external insulating sheath provides additional UV protection to minimise rapid discolouration to ensure your install looks great for many years, even in direct sunlight! The outer sheath is also suitable for electrical installations within concrete.
- Specially formulated Ultraspeed inner coating and carefully designed internal spirals ensure minimal friction to the electrical wires to assist with installation speed.
- Made in Europe
Use | Outdoor, high UV exposure areas |
Sizes OD | 20mm, 25mm |
Sizes ID | 14.1mm, 18.3mm |
Material | PVC SPVC (outer sheath) |
Resistance to flame propagation | Non-flame propagating |
Dielectric Strength | Electro-insulating Characteristics |
IP Rating | IP65 |
Colour | Grey |
Resistance to UV | Protection against UV radiation with minimal yellowing - 'T' rated |
Rating | Medium Duty |
Temperature Range | -25°C to +60°C |
Resistance to Compression | Minimum 750 N / 5cm |
Resistance to Impact | Minimum 2 Joule |
Compliance
AS/NZS 2053.1
AS/NZS 2053.5
EN 61386-22
